Digital Cameras: Does Pixel Size Matter?
Factors in Choosing a Digital Camera
(Does Sensor Size Matter?)

by Roger N. Clark

Contents


All images, text and data on this site are copyrighted.
They may not be used except by written permission from Roger N. Clark.
All rights reserved.
If you find the information on this site useful, please support Clarkvision and make a donation (link below).


Introduction

In today's Digital Camera market there is a bewildering array of models to choose from. I recently faced such a decision when I wanted to buy a small point and shoot digital camera. I wanted a small size, high megapixel count, fast response time (low shutter lag), and low noise camera. I did not get what I wanted because it did not exist at the time of my purchase. After a little research, I find I never will get what I wanted, unless someone comes up with a way to break the laws of physics. I hope to show you what I mean in this article.

Counting Photons

The sensor in today's digital cameras uses a charge-coupled device, CMOS sensor or other similar device that is an array of pixels. Each pixel, is a semiconductor material that absorbs photons and liberates electrons. The electrons are gathered and held in what is called a potential well, or voltage well that prevents the electron from drifting away. The analogy is a bucket of water holding rain drops, and the photons are the rain drops falling on the buckets. This analogy is shown in Figure 1a. But the Figure 1a analogy is incomplete: we need a lens. Figure 1b shows a more complete analogy: funnels collect rain drops and deliver the water to buckets.


Figure 1. Photon rain: the analogy of photons falling into buckets which collect the rain drops. A larger bucket collects more drops. Given two sensors with equal numbers of pixels, and each with lenses of the same f/ratio, the larger sensor collects more photons yet has the same spatial resolution. The lens for the larger sensor would have a longer focal length in order to cover the same field of view is the system with the smaller sensor and the lens will also have a larger aperture diameter, thus collecting more light. It is the larger aperture that delivers the light to the pixel and the larger pixel simply enable collection of the increased light delivered by the lens. This is shown in Figure 1b.

It is generally assumed on the internet that larger pixels collect more light and that cameras with larger pixels have greater low light sensitivity. Larger pixels do have higher maximum signal capacity per pixel (called full well capacity). But that is like saying my bucket has more water in it just because it is a 5-gallon bucket and you only have a one gallon bucket. But did I actually put any water in the bucket? In one recent argument, an internet poster said put out a thimble next to a swimming pool and see which one collects more rain drops. Well, that is obvious but the analogy to light and cameras is lacking one thing: a lens, or in the case of rain drops, a funnel. The rain drop analogy is good because like raindrops, light is composed of photons (particles of light) that randomly arrive at our eyes and camera lens. To illustrate this concept, consider the graphic in Figure 1b. The photon rain analogy can be considered raindrops on a rainy day, or photons coming to our camera. The orange lines represent funnels in the rain, or a lens focusing light onto a pixel in a camera. Two different cameras are illustrated, one having large pixels and one having pixels half the size. The lens collects the light and as long as the lens diameters are the same. This results in equal performance as long as the pixel does not overflow (see Figure 9 caption). The amount of rain (photons) in each bucket (pixel) is the same. In practice, depending on the camera technology, sensor and camera electronics noise can make one camera versus another better or worse performer, in one case making the large pixel camera the better low light performer, and in another the camera with small pixels the better performer. Either way, the key to low light performance is collecting as much light as possible.


Figure 1b. Raindrops (blue) as an analogy to photons entering a camera. The buckets ("pixels") fill with water (blue), but the orange funnels collect the rain and focus it onto the buckets (pixels). In this case the large end of the funnels have the same diameter so collect the same amount of rain per unit time (the exposure). The ONLY difference is the small bucket will fill up faster, but that is not a problem in low light situations. Small buckets are NOT a disadvantage. The funnel diameter controls how much rain goes into the bucket, not the size of the bucket. It is the same with cameras, lenses, and pixels. The angle "a" is the is the angular size of a pixel and is the same for both the large and small pixel in this example. In a camera, both cameras would get the same amount of light per pixel, show the same noise, have the same pixels on the subject, and have the same depth of field.

When the image is ready to be read out, the signal from the pixel is sent to an amplifier and then an analog-to-digital (A to D) converter. In the water bucket analogy, the walls of the bucket must be thick enough so the water does not leak out and get into the adjacent bucket. This sets minimum sizes for the walls and sizes of the hole the water can fall into, and in the electronic world, how big the electron well walls must be, how far apart they must be, and restricts the size of the active area where photons are absorbed to generate electrons. Even if some advances are made in these areas, there is one fundamental limit: photon counting statistics.

In the analogy of the photon rain filling buckets, as shown in Figure 1, the, larger the bucket, the more drops that can be collected in a given amount of time. This is important for a very fundamental reason: the accuracy of the signal measured is directly proportional to the size of the signal. In the physics of photon counting, the noise in the signal is equal to the square root of the number of photons. What we perceive as noise in our digital camera images is the signal-to-noise ratio, S/N. Only at the very lowest signal levels does camera electronics noise become a factor (e.g. low level banding). Example photon noise and S/N:

Table 1
Photons Noise signal-to-noise 9 3 3 100 10 10 900 30 30 10000 100 100 40000 200 200

The Light that is absorbed in the silicon sensor does so over a very limited range. Back to the bucket in the rain analogy. Making a deeper bucket does not help with electronic sensors because the light will not penetrate any deeper. So to collect more light, only area matters, and this is why in Figure 1a, and 1b the bucket depth is the same for small and large pixels.

Why is this important? It turns out that the noise in good modern digital cameras is dominated by photon counting statistics, not other sources. This is explained in detail at: The Signal-to-Noise of Digital Camera images and Comparison to Film, and How to Interpret Digital Camera Sensor Reviews. Some of the data from articles on the clarkvision.com site are shown here for several cameras from top end professional DSLRs to prosumer DSLRs, and Point and Shoot cameras, "P&S." Figure 2 and 3 show that the the top pro model as well as the consumer point and shoot camera discussed here are photon noise limited. In fact, all modern digital cameras tested in the last few years have been shown to be photon noise limited at signal levels above a few tens of photons. For example, see sensor analyses and further references at: http://www.clarkvision.com/reviews/.


Figure 2. The Canon 1D Mark II is photon noise limited at all ISO settings. Only photon noise shows the square-root dependence on signal seen here.


Figure 3a. The noise from the Canon S70 point and shoot consumer camera is photon noise limited for all levels above about 10 photons. Blue points are measured values, and the red line is a model with: maximum signal = 8,200 photons (electrons), read noise = 4.1 electrons. Only photon noise shows the square-root dependence on signal seen here.


Figure 3b. The signal-to-noise from the small sensor, 2.3 micron pixel pitch, Canon S70 point and shoot consumer camera is compared to that from a large sensor, 8.2 micron pixel pitch, Canon 1D Mark II DSLR camera. The signal-to-noise ratio of an 18% gray card is at 0-stops, with brighter parts of the image are to the right, and darker parts to the left, following each curve. For example, the Canon 1D mark II at ISO 100 would record a signal-to-noise ratio of about 100 on the 18% gray card but only about 10 in shadows at -5.5 stops (follow the magenta line). The 1D Mark II has about 13 times the light collection ability of the small S70 camera. The lower slopes of the lines above a signal-to-noise ratio of about 8 indicates the noise in the images are photon noise dominated, while at lower ratios, the signal becomes increasingly read noise dominated.

An example of large versus small pixels and the effects on image quality is illustrated in Figures 4 and 5. BUT DO NOT BE FOOLED--READ THIS ENTIRE PARAGRAPH! The common idea on the internet is that the sensor is responsible for the increased light and noise performance. The idea is that the smaller pixels in the smaller sensor of the S70 camera collect less light. Here is the typical photographer setup equalizing exposure time, ISO and f-ratio between two cameras. Figure 4a and 4b shows the full scene recorded by two cameras set at the same ISO (ISO 400), same f/stop (f/4.5), and same exposure time (1 second). The pixel pitch (the distance from one pixel to the next; the actual pixel area sensitive to light is slightly smaller) is 8.2 microns for the large sensor, large pixel camera (Canon 1D mark II) versus the small sensor, small pixel camera (Canon S70). Both cameras have almost identical read noise at ISO 400: 5.6 electrons for the 1D Mark II and 4.3 electrons for the S70, thus the S70 has a slight advantage! But despite the read noise advantage, the larger pixels of the big camera collects so much more light per pixel that the image quality is much better than the small pixel camera (Figure 5). WHY? The lens apertures are different! The light is delivered by the lens, and the lens is the real reason the large pixels are able to collect more light.


Figure 4a. The Canon 1D Mark II DSLR full test scene: books in a bookshelf. ISO 400, f/4.5 1, second exposure. The lens is 44 mm focal length, f/4.5 so the lens aperture diameter = 9.8 mm.


Figure 4b. The Canon S70 Point and Shoot camera full test scene: books in a bookshelf. ISO 400, f/4.5, 1 second exposure. The lens is 13.2 mm focal length, f/4.5 so the lens aperture diameter = 2.9 mm.


Figure 5. Full image crops from Figures 4a and 4b. The crops are from raw converted 16-bit TIF images converted by Canon Zoombrowser software with the same (default) settings for both cameras. Both cameras recorded the same exposure at the same ISO, and same f/ratio: ISO 400, f/4.5, 1 second exposure. The larger lens diameter collected more light and fed that light to the pixels of the 1D Mark II to produce higher signal-to-noise images than the small lens diameter feeding the small sensor, small pixels of the S70. Both cameras are photon noise limited, as are these images. The signal-to-noise ratio is abut 3.5 times higher for the 1D Mark II image, close to the ratio of the lens aperture diameter, the pixel pitch, and the sensor sizes from each camera. The CAUSE is the lens which delivered more light to the 1D Mark II image, making the better image. The sensor and pixels are just buckets to collect the light delivered by the lens.

True Equalization of Light Between Cameras

At this point, you may be quite confused. The internet is full of people saying larger format cameras with larger pixels are more sensitive, and the show images to prove it. But what is the real cause? In such cases, photographers try and equalize the parameters they are familiar with: exposure time, f-ratio, and ISO, the so-called exposure triangle. But equalizing these three things does not necessarily mean the the actual light delivered to the sensor is equalized. If the light is not equalized, the actual sensor performance can not be accurately assessed.

Of the three parameters, exposure time, f-ratio, and ISO, only exposure time is the true parameter that is actually equalized in terms of total amount of light when set to a constant value between cameras. ISO is not constant between cameras. For example, ISO 100 on the Canon 1D Mark II shown here has a range of 0 to 79,900 photons (photoelectrons), while the S70 has a range of only 0 to 4100 photons. Constant f-ratio delivers constant light density to the focal plane, but NOT the same total light from the subject! Lens aperture area determines the total light collected from the subject.

To equalize the light delivered to the sensor and have it digitized equally, one needs to make 4 parameters equal: 1) exposure time, 2) Photoelectron digitization range, 3) lens aperture area (lens aperture diameter, technically called the entrance pupil), and the number of pixels on the subject equal. For the Cameras used above, I equalized these three parameters and show the results in Figure 6. When the pixels on the subject and lens aperture area are equalized, this is called equalizing the Etendue. Then for the same exposure time one delivers the same amount of light to the sensor. Then sensor characteristics can be fairly compared (Figure 6). When that is done, the images are virtually indistinguishable, including apparent noise and depth of field.


Figure 6. Illustration of equal Etendue results in the same image quality independent of sensor size, pixel size, and focal length or f/ratio!


Dynamic Range

A large dynamic range is important in photography for many situations. The pixel size in digital cameras also affects dynamic range. Dynamic range is defined here to be the maximum signal divided by the noise floor at each ISO. The noise floor is a combination of the sensor read noise, analog-to-digital conversion limitations, and amplifier noise. These three parameters can not be easily separated when evaluating digital cameras, and the combinations is generally called the read noise (or apparent read noise). As you might have surmised by now, with the larger pixels collecting more photons, those larger pixels also have a a potential for higher dynamic range if the camera's electronics have the specifications to handle the range. Figure 7 shows the measured dynamic range from 3 cameras with significantly different pixel sizes as a function of ISO. The full sensor analyses for these 3 cameras (as well as other cameras) can be found at: http://www.clarkvision.com/articles/reviews/. Large pixel cameras are often limited by noise in downstream electronics, such as from the analog-to-digital converters. If such noise could be eliminated, the dynamic range could increase in cameras with large pixels by about 2 or more stops when operating at low ISOs. Indeed, some cameras from Nikon and Sony do show dynamic ranges a little larger than that shown in Figure 7. The current smallest pixel cameras do not collect enough photons to benefit from higher bit converters.


Figure 7. The dynamic range for 3 different cameras is shown, along with models that show what performance would be if electronics noise after the sensor was zero. Large pixel cameras can have a larger dynamic range. The small pixel camera has a very good dynamic range at low ISO, but that range rapidly deteriorates with increasing ISO. The larger pixels have greater dynamic range at all ISOs, beating smaller pixel cameras. Further, the large pixel cameras have high dynamic range over a larger range of ISO. The measured dynamic range (symbols) is shown with models of the expected dynamic range (dashed lines). The dynamic range is often limited by the A/D converter and other electronics in the system, illustrated by the measured data falling below the model at lower ISOs. The dynamic range for more cameras can be found at Digital Camera Sensor Performance Summary http://www.clarkvision.com/articles/digital.sensor.performance.summary and http://www.clarkvision.com/articles/reviews/.


Sensor Sizes

Sensor sizes in smaller cameras are specified by a strange parameter, like 1/1.8" which dates from TV camera tubes from the 1950s. In my opinion, this is simply to confuse consumers as to the true nature of the small sensors. See Sensor Sizes http://www.dpreview.com/learn/?/Glossary/Camera_System/Sensor_Sizes_01.htm for more details. Here are some simple translation numbers

         Table 5
               Sensor Size (mm)
Type            Width   Height
1/6             2.40    1.80
1/4             3.60    2.70
1/3.6"          4.00    3.00
1/3.2"          4.54    3.42
1/3"            4.80    3.60
1/2.7"          5.37    4.03
1/2.5"          5.76    4.29
1/2.3"          6.16    4.62
1/2"            6.40    4.80
1/1.8"          7.18    5.32
1/1.7"          7.60    5.70
1/1.6"          8.08    6.01
2/3"            8.80    6.60
1"             12.80    9.60
4/3"           18.00   13.50
APS C          23.70   15.70 (1.6x crop; also called 1.8")
APS-H          28.7    19.1  (1.3x crop)
35 mm film     36.00   24.00

Diffraction

Diffraction also limits the detail and contrast in an image. The diffraction spot diameter in the focal plane of an optical system is proportional to the f/ratio according to the formula: Diffraction spot diameter = 2 * 1.22 w * f / D = 2.44 * w * f_ratio, where w = wavelength, f = focal length, D = aperture diameter, and f_ratio is the f/ratio of the optical system. The diffraction spot size is given in the table below:

                          Table 6
        ================================================
                     red=     Green=    Blue=
                      0.6      0.53      0.47
                    micron   micron    micron
        ================================================
        f/ratio     diffraction spot diameter in microns
        ================================================
               2      2.9       2.6       2.3
             2.8      4.1       3.6       3.2
               4      5.9       5.2       4.6
             5.6      8.2       7.2       6.4
               8     11.7      10.3       9.2
              11     16.1      14.2      12.6
              16     23.4      20.7      18.3
              19     27.8      24.6      21.8
              22     32.2      28.5      25.2
              32     46.8      41.4      36.7
              45     65.9      58.2      51.6
              64     93.7      82.8      73.4
        ================================================

The wavelengths are the approximate centers of the red, green and blue filters in digital cameras. Note the diffraction size is larger for redder colors.

Compare the diffraction diameters with pixel sizes in digital cameras. The Canon 1D Mark II discussed above has 8.2 micron pixel spacing, and with the blur filter which is used on most Bayer-sensor cameras, the resolution is perhaps 30% worse, so about 11 microns. At about f/8 the camera pixels + blur filter matches the blur due to diffraction. But the same trade point in the small sensors in the Canon S60, with 2.7 micron pixel spacing, occurs at f/2.8. This diffraction spot size versus pixel size trade point occurs at a 20% degradation in high frequency contrast (80% MTF, the Modulation Transfer Function). The contrast reduction is shown in more detail in Figure 8. Diffraction at this point is beginning to limit resolution but not seriously so. But using apertures smaller than this trade point means the image resolution is becoming more limited by diffraction, not the sensor. Unless you work with very fast, sharp, lenses all the time, you need larger pixels in order to maintain high contrast in the pixel-to-pixel image detail. Thus, cameras with a larger sensor containing more pixels have the advantage against being limited by diffraction. If you decrease pixel size, of course you don't lose resolution in the image, just the pixel-to-pixel contrast in fine details will be less.


Figure 8. Diffraction affects image detail by reducing contrast. The technical term for the contrast reduction is called the Modulation Transfer Function (MTF) and describes the contrast the camera delivers as a function of the spacing of lines (called the spatial frequency). Here the spatial frequency is expressed in terms of pixel spacing. As the f/stop number increases (e.g. f./4 to f/8), the diffraction spot becomes larger, and fine detail in the image becomes reduced in contrast. The red, green and blue lines show the diffraction effects for red, green and blue wavelengths of light for f/ratios 1, 2, 4, and 8.


Enlargement

In order to make a given print size, the image must be enlarged from the small image in the focal plane of the camera. For example, say you want to make 8 x 10 inch (203 x 254 mm) prints. If your sensor is like the Canon S60 at 7.18 x 5.32 mm, one would need about a 36 times enlargement. Such extreme enlargement would magnify any lens imperfections, and vibration during the exposure. The larger sensor of the 1D Mark II, with its 28.7 x 19.1 mm sensor, needs only a 10.6 times enlargement (making an 8 x 12 inch print), or 3 times less enlargement of lens imperfections and vibration than the S60.

Traditionally in photography, larger formats have produced better images on the final print. A major factor in image quality is the enlargement factor. Large formats (like 8x10 or 4x5 film and now large format digital scanning backs) produce spectacular large prints that can't be matched by smaller (e.g. 35mm and smaller) formats. Those factors scale to even smaller formats of present point and shoot small sensor digital cameras.

The f/ratio Myth

There is a common idea in photography that exposure doesn't change between different size cameras when working at the same f/ratio. For example, the sunny f/16 rule says a good exposure for a daylight scene is 1/ISO at f/16. Thus for ISO 100 film, you use a 1/100 second exposure on an 8x10 camera at f/16, a 4x5 camera at f/16, a 35mm camera at f/16, an APS-C digital camera at f/16, down to the smallest point and shoot camera at f/16 (assuming the small camera goes to f/16). The myth is that every camera will provide the same signal-to-noise images as long as the same exposure time and f/ratio lens is used, from the camera with the smallest sensor, to the camera with a large sensor.

The concept of constant exposure for a given f/ratio leads people to think cameras scale easily and still give the same image. But there is a fallacy in this idea, and that is the spatial resolution on the subject. The smaller camera, even at the same f/ratio, has a smaller lens which collects a smaller number of photons per unit time. The smaller camera gets the same exposure time because the UNIT AREA in the focal plane represents a larger angular size on the subject. Exposure is not the same as light gathered. Exposure is a relative measure of how much a pixel might be filled. The larger pixel can collect more light before it is called half full (think of large and small buckets of water: the small bucket at half full holds less water than the larger bucket at half full).

The rate of arrival of photons in the focal plane of a lens per unit area per unit time is proportional to the square of the f-ratio. Corollary: if you keep f/ratio constant, and change focal length then the photons per unit area in the focal plane is constant but spatial resolution changes.

So how does this apply to making smaller cameras?

The problem is that if you scale a camera down, say 2x in linear size, the aperture drops by 2x in diameter, the focal length drops by 2x (to give the same field of view), the sensor size drops by 2x (linearly or 4x the area), and the pixel size drops by 2x (linearly or 4x the area, to give the same spatial resolution on the subject). The aperture has collected only 1/4 the number of photons. If we kept the same sensor, then each pixel would collect the same number of photons because each pixel now sees a larger angular area (4x larger). But we want the same resolution, so the pixels are 2 times smaller (4x smaller area). The smaller pixels each collect 1/4 less photons since their area is divided by 4 to keep spatial resolution constant and the fundamental cause of the lower light collected is due to the smaller lens because it collects and delivers a smaller number of photons to the pixels. The cause is NOT due to the smaller pixels.

Another way to look at the problem is aperture collects light, the focal length spreads out the light, and the pixels are buckets that collect the light in the focal plane. BUT THE TOTAL NUMBER OF PHOTONS DELIVERED TO THE FOCAL PLANE IS ONLY DEPENDENT ON APERTURE (ignoring transmission losses of the optics). Thus, photons delivered to a pixel for a given resolution on the subject goes as the square of the aperture (and camera size when the lens is scales with the camera format size and f-ratio is maintained)! Decreasing your camera by 2x means 4x less photons per pixel if you want to maintain field of view, f-ratio and megapixel count!

This is just what we observe with small cameras: their smaller sensors have smaller full well capacities, that get filled for a given exposure time with a smaller number of photons that is delivered by the smaller lens. That in turn means higher noise because there are fewer photons. But this scaling is ONLY TRUE if we scale the lens down with the smaller sensor. But IF we keep the lens aperture area the same, then we deliver the same amount of light in the same exposure time.

Example: a full frame 20 megapixel camera and 2x crop sensor 20 megapixel camera. If you use a 50 mm f/4 lens on the full frame (FF) camera then to get the same light, same apparent noise, same pixels on subject and same depth of field, we would use a 25 mm focal length f/2 lens on the crop camera. In both cases, the lens aperture diameters are 12.5 mm.o

Let's extend that to lower light faster lenses. Put a 50 mm f/1.4 lens on the full frame camera. To have equal light with the crop camera, one would need a 25 mm f/0.7 lens. But such a lens does not exist! So the larger format camera enables one to use larger aperture lenses that do not exist for smaller format cameras. That also means the smaller camera would not be much smaller, due to the lens, and might be more expensive due to the lens specifications.

For photon noise limited cameras with constant f-ratio lens, signal-to-noise ratio achievable in an image for constant exposure time is the square root of the number of photons collected, so signal-to-noise ratio scales linearly with the camera pixel size (again for constant f-ratio lenses). That concept is illustrated in Figure 5, above: the small sensor camera with its smaller lens produced a noisier image than the larger sensor camera with its larger lens even though the f/ratio, exposure and ISO are the same for the two cameras (which as we have seen does not mean equal light). See also: The f/ratio Myth and Digital Cameras http://www.clarkvision.com/articles/f-ratio_myth

Check out this web page for more info on this subject: http://www.stanmooreastro.com/f_ratio_myth.htm , and Characteristics of Best Digital Cameras and Lenses for Nightscape and Astro Photography.

The Depth of Field Myth

After understanding the concepts in the f/ratio myth, there is another major implication of scaling sensors. Given the identical photon noise, exposure time, enlargement size, and number of pixels giving the same spatial resolution (i.e. the same total image quality), digital cameras with different sized sensors will produce images with identical depths-of-field. (This assumes similar relative performance in the camera's electronics, blur filters, and lenses.) The larger format camera will use a higher f/ratio and an ISO equal to the ratio of the sensor sizes to achieve that equality. If the scene is static enough that a longer exposure time can be used, then the larger format camera will produce the same depth-of-field images as the smaller format camera, but will collect more photons and produce higher signal-to-noise images. Another way to look at the problem, is the larger format camera could use an even smaller aperture and a longer exposure to achieve a similar signal-to-noise ratio image with greater depth of field than a smaller format camera. Thus, the larger format camera has the advantage for producing equal or better images with equal or better depth-of-field as smaller format cameras. The details of these concepts are discussed here: The Depth-of-Field Myth and Digital Cameras http://www.clarkvision.com/articles/dof_myth

Different Sized Pixels in the Same Sized Sensor

We have considered cameras with the same number of pixels and different sized sensors and shown that cameras with larger sensors and larger pixels collect more light given the same f/ratio lens and field of view, thus have better low light and high ISO performance. But now we also have choices of different cameras having the same sized sensors but with pixels varying in size and number. What are the implications of this situation?

There are apparently heated debates on the net regarding this issue with passionate arguments for smaller and for larger pixels in the same sized sensor. Many have used data in this article and my Digital Camera Sensor Performance Summary article to argue both sides. Like many positions on extremes, some of these arguments ignore key factors.

The argument for smaller pixels goes like this. Smaller pixels in the same sized sensor record finer details. You can always average pixels to get back to effectively larger pixels. In high signal parts of an image this argument is correct except for one factor: smaller pixels have lower dynamic range (see Figure 7, above). If your smaller pixel blow the highlights, you have lost all the image detail. But if you don't blow the highlights, smaller pixels are better when you have plenty of light. The noise in the image will be dominated by photon noise (the best one can do) and you can in software trade noise for resolution. And by averaging pixels, one can improve the dynamic range. So higher megapixel cameras have merit.

In a perfect camera, the only noise you would record would be that from photons (the ultimate physical limit). But cameras have other sources of noise (see Digital Camera Sensor Performance Summary), including read noise, electronics noise, noise from dark current (thermal noise), and fixed pattern or banding noise. This changes the equation on pixels, low light performance, and high ISO photography.

As light levels fall, whether in the shadows of a daytime scene, indoor photography with low light, to night photography, cameras must make do with less light for the image. This means that the electronics noise in the camera becomes a greater portion of the total noise we perceive in images. And it is this fact that can limit the idea of making smaller and smaller pixels. This electronics noise is also a factor in the reduced dynamic range of smaller pixels. So with the increased apparent noise, lower dynamic range, and the fact that lenses can not deliver finer and finer detail because they become diffraction limited, the image quality can't increase forever as pixel size decreases. Another factor in small pixels is the absorption length of photons in the silicon sensor: it ranges from about 1 micron for blue light to over 7 microns for red light (see Table 1B at Digital Camera Sensor Performance Summary). The absorption length will also limit the image detail, especially toward red colors. So there are detrimental effects of pixels that are too small.

Now lets consider large pixels. The ultimate in high signal-to-noise ratio, high dynamic range, and high ISO performance would be one large pixel. Obviously a camera with one large pixel does not form a very good image. Clearly some pixels are necessary to provide an image, and recent full frame cameras with 20+ megapixels deliver outstanding image detail. Too few pixels are bad for image quality and too many pixels are bad for image quality. So there must be an optimum.

My Apparent Image Quality (AIQ) model, discussed in more detail in Digital Camera Sensor Performance Summary shows an optimum pixel size (Figure 9). For cameras with diffraction limited lenses operating at f/8, the model predicts a maximum AIQ around pixels of 5 microns. Many APS-C cameras are operating near that level. As of this writing, full frame 35 mm digital cameras exit with 36 to 50 megapixels with between 4 and 5 micron pixels with impressive image quality, but only if used with excellent lenses.


Figure 9. Apparent Image Quality, from Digital Camera Sensor Performance Summary. The models closely predict performance for modern cameras (within about 10% for large pixels, and 20% for small pixels). Older cameras and sensors fall below the model, e.g. typically due to low fill factors. Higher quantum efficiency (QE) sensors than the model (45%) would plot above the model (by a factor of square root 2, 1.41x higher AIQ for a ~100% QE sensor). Solid colored lines indicate constant sensor size in megapixels. Dashed colored lines indicate constant format sized sensors. The "Full-Frame" sensor is the same size as 35-mm film. As one moves to the left along a constant format line, AIQ first increases until diffraction begins to take effect, then AIQ decreases. Diffraction at f/8 is used for the Full Frame, 1.3x-crop, and 1.6x-crop sensors, and f/7 for the 4/3 sensor (long dashed lines), f/4 for the Full Frame and 2/3" small-format sensors, and f/2.8 for the smallest sensor shown, 1/1.8" (short dashed lines). The smaller f/ratios are needed as sensor size decreases in order to make the model fit observed data. This indicates smaller format cameras must have very high quality lenses in order to deliver performance at high megapixels. Diffraction limits the effective megapixels. When pixels become very small, they hold so few electrons that dynamic range suffers, and this causes the turn down in AIQ at pixel sizes below 2 microns pixel pitch. See the discussion of diffraction, above, which will further limit AIQ. For example, the AIQ for the Canon 7D plots above the model line for its 1.6x crop sensor. But that AIQ will only be realized of the lens used with the camera is diffraction limited below f/8.


Same Lens, Different sensor and Pixel Size

Now let's examine a common example of using the same lens on different cameras, so that sensor size and pixel sizes are different. The amount of light captured in a pixel is dependent on the lens delivering the light. There is an additional factor in cameras and lenses: the area the pixel covers. If we equalize the area, and thus pixels on subject, then using the same lens, same f/ratio, same exposure time, the light per pixel is the same. We can equalize the pixel area between a camera with large pixels and one with small pixels by simply adding pixels, or fractions of pixels together. Figure 10 shows such an example.

The lens delivers the light. The pixel is just a bucket. Below in Figure 10 is a comparison of images made with a full frame and 1.6x crop cameras. If we believed the internet myth that larger sensors are more sensitive, one would expect a noise difference between full frame and crop cameras to be the square root of the pixel areas, or sqrt(2.59) = 1.6, which would make the crop camera image noticeably noisier. Clearly, that is not the case in Figure 10. Web sites that show a differences between crop and full frame cameras are typically changing the lens aperture area between cameras, thus the amount of light collected.


Figure 10. Comparison of images made with a full frame and 1.6x crop cameras. The ratio of the pixel areas is 2.59. Focusing on the subject, not the pixel (after all what is the subject in a photo: the subject, or the pixel?), I binned the smaller pixels of the 1.6x crop camera to the same pixels on subject in the full frame. By resampling to the same pixels on the subject, we see that the signal-to-noise ratio (S/N) is essentially the same in the uniform areas (agreement to better than 1 percent), but the smaller pixels of the crop camera actually record fainter stars and more detail, even after resampling.

Figure 11 is another example using a 7D at ISO 6400, which produces a quite noisy image. Compare that to the 5DII, with its larger pixels produces an image with less apparent noise, but lower spatial resolution, and then compare to the 7D with pixels scaled then averaged 2x2: a pretty clean image in comparison. The scaling up by 1.35x does not change the noise, and the 2x2 pixel average simply has the Etendue made larger and equal to that for the 5D Mark II image. Note that the TOTAL light from the subject is the same for the original 7D image and the scaled, 2x2-pixel averaged image. The noise in the 7D resampled image is less because the is more light per pixel in the resampled image. The noise also appears less in the resized 7D image than that in the 5D Mark II image. This is because the 7D sensor has slightly greater system sensitivity than the older generation 5D Mark II, so the 7D collected a little more light, making a higher signal-to-noise ratio image. This proves the 7D is actually a better low light camera than a 5D Mark II.


Figure 11. Comparison of 7D, 5DII and scaled 2x2 pixel averages of the 7D image at ISO 6400. The 2x2 pixel average was performed in ImagesPlus. This rescaling and pixel averaging make the 7D Moon image the same size as the Moon in the 5D Mark II image. If the two cameras had equal system sensitivities, the noise would be identical. The rescaled 7D image on the right actually shows less noise than in the 5D Mark II image because the 7D has slightly greater system sensitivity. No sharpening and no noise reduction software was run on any image.

Another factor to consider regarding cameras is being able to change lenses. Very fast wide angle lenses are only available in single focal lengths (commonly known as prime lenses) with only a few rare exceptions. Most zoom lenses are not as fast and produce lower quality images (there are some exceptions). This generally means a DSLR or mirrorless camera with interchangeable lenses. Note that too much use of live view, whether mirrorless camera or DSLR heats the sensor increasing dark current noise and that may make such comparisons different. Once a sensor heats up, it can take a half hour or more to cool back to ambient temperatures.

Another factor that may affect performance is pattern noise, or banding. Older model cameras may have more banding problems than newer models and the pixel rescaling my limit the effectiveness of comparisons like that in Figure 10 and 11. But with modern low noise, low banding cameras, one can trade spatial detail for noise, and pixel size is less of a concern. Low light performance is dominated by the lens collecting the light, not on pixel size and sensor size.

Discussion and Conclusions

I have demonstrated in this article that the lens aperture collecting the light is the most important factor with modern cameras, not sensor size or pixel size. This is true for many cameras, sensors sizes and pixel sizes. A larger sensor enables one to use larger lenses to collect more light. But if the same aperture diameter lens can be used on a smaller format camera, then images can be virtually identical. This concept is explored more in part 2.

But as one pushes extremes, either very small pixels, less than a couple of microns, other factors come into play, including diffraction which reduces contrast and detail, absorption lengths of photons in silicon, and pixel dynamic range can limit the ability to get performance obtainable with larger systems. For example, if one is using a fast lens, like 50 mm f/1.4 on a full frame sensor, scaling down the sensor by 6x would require a 6 times shorter focal length (8.3 mm), if one wants to maintain the same field of view. With the same aperture diameter (35.7 mm) to maintain light collection, that would require an f/0.23 lens (8.3/35.7)! Such lenses do not exist. The requirements to maintain performance of a larger format system in a smaller format camera increase as the format decreases, and at some point becomes impossible or prohibitively expensive. The usual reason people buy smaller format cameras is lower cost, lighter weight and smaller bulk; performance is an afterthought.

For moderate systems, e.g. 1.6x crop versus full frame DSLRs, by understanding the Etendue concepts presented here and elsewhere on this website, one can in many cases get similar performance between the two systems. This assumes one can maintain the lens aperture diameter on the smaller system.

Small versus large pixels matter less in modern sensors: with the low noise (read noise and camera electronics noise) available in many of today's cameras (circa 2014+) one can synthesize large pixels from a sensor with small pixels obtaining similar (or even better) performance. This was not always the case. Older digital cameras had high read noise and high camera electronics noise. Adding pixels together meant adding significant noise, limiting the effectiveness of larger pixel synthesis. In the near future, read noise + downstream camera electronics noise should be significantly below 1 electron (circa 2014+ it is typically 1 to 3 electrons in some cameras). Below one electron one can pretty much rely on post processing to trade noise with spatial resolution at the lowest light levels. Such post processing binning is being done today (2015+) but with a small amount of added noise when adding pixels together (Figures 10, 11).

We do observe a difference in image quality in the images output from a camera with larger versus small pixels. But such difference can be effectively mitigated in post processing as illustrated in Figures 10 and 11.

When choosing between cameras with the same sized sensor but differing pixel counts, times have changed. A decade ago, I would have chosen the camera with larger pixels (and fewer total pixels) to get better high ISO and low light performance. Today I would choose the higher megapixel (thus smaller pixels). Modern cameras with high megapixel count, low read noise and low electronics noise allow one to trade resolution and noise. If one wants reasonable dynamic range in a high megapixel camera, the pixels must still be large enough to hold enough photoelectrons to give the dynamic range. Currently (circa 2016), that is not much smaller than 4 micron pixel spacing. For example, the 50 megapixel Canon 5DS(r) fits this criteria, and Nikon's D800 and D810 are in the same league.

Pixels smaller than 4 microns can often be limited (lower contrast and loss of fine detail) by diffraction. But now that system noise is low in modern cameras, adding pixels together to synthesize an image from a sensor with larger pixels, diffraction limited smaller pixels is less of a concern.

Do note, however, that photoshop (CS6 to CC) currently does not have pixel binning tools. If you want to do pixel binning, look at astronomical image processing programs.

See also: Characteristics of Best Digital Cameras and Lenses, and
Film Versus Digital Executive Summary.
Also, see the article Dynamic Range of an Image which shows that real scenes can have over 10 photographic stops of dynamic range (a factor of over 1000).
Then explore the article on The Signal-to-Noise of Digital Camera images and Comparison to Film.


If you find the information on this site useful, please support Clarkvision and make a donation (link below).

Notes and References

This page shows images and noise graphs of some point and shoot digital cameras compared to a DSLR. The results are similar to the research presented on this page. http://www.dpreview.com/reviews/sonydscf828/page14.asp

DN is "Data Number." That is the number in the file for each pixel. I'm quoting the luminance level (although red, green and blue are almost the same in the cases I cited).

16-bit signed integer: -32768 to +32767

16-bit unsigned integer: 0 to 65535

Photoshop uses signed integers, but the 16-bit tiff is unsigned integer (correctly read by ImagesPlus).

The fundamental error in measuring a photon signal is the square root of the number of photons counted, Poisson Statistics. The maximum number of photons one can count with a sensor is the max number of electrons in that can be held in the well. There is one electron per photon. If one fills the pixel well with 40,000 electrons, then the noise in the signal is square root 40,000. So whatever the signal is, the error (noise) is square root of the number of electrons (photons). The more photons counted, the higher the signal-to-noise. The signal-to-noise = # photons/square root(# photons) = square root(# photons) In the shadows in an image, one may get only a few hundred photons, so the noise is square root of those few hundred.

The Poisson Distribution http://mathworld.wolfram.com/PoissonDistribution.html

Signal-to-Noise Ratio in digital imaging: http://www.photomet.com/library_enc_signal.shtml

Photon noise: http://www.roperscientific.de/tnoisesrc.html

Canon's Powershot S60 camera report. http://www.canon.com/camera-museum/tech/report/200408/report.html

CMOS Fill Factor explained: FillFactory's High Fill Factor N-Well Pixel® (US Patent 6,225,670) http://www.fillfactory.com/htm/technology/htm/high_fill.htm

When digital cameras need large pixel areas http://www.kodak.com/global/plugins/acrobat/en/digital/ccd/papersArticles/interlineLargePixels.pdf

The Two Classes of Digital Cameras http://www.kenrockwell.com/tech/2dig.htm

More on the f/ratio Myth: http://home.earthlink.net/~stanleymm/f_ratio_myth.htm


NOTE: This is part 1 in a series. Part 2 is at:
Digital Cameras: Does Pixel Size Matter? Part 2: Example Images using Different Pixel Sizes.
